VDC 40 x 40 x 10mm Axial Fan

Detail Specifications

Low-cost DC fan , with sleeve bearing, offering low noise and high air flow.
•5.7CFM airflow
•20dBA noise level
•4800rpm rated speed
•31000hrs life expectancy
•-10°C to +70°C
•40mm long, 40mm wide, 10mm deep
•Weight 24g
•Approved to UL, CUL, TUV, CE
•Frames and impellers made from black UL94V-0 glass filled polyester
•Fitted with 300mm flying leads

15005-001

•5V
•0.11A load current
•0.55W power rating

15005-002

•12V
•0.08A load current
•0.96W power rating
