Connecting Plug
- Model Code: 13011
- Brand:
Detail Specifications
| Model Code | Manufacturer Code | Insulator | Body | Spring | Surface | Rated voltage/current |
| 13011-001 | CP121 | ABS | Brass | Beryllium copper | Gold plated | 30Vac-60Vdc/Max.10A |
| 13011-002 | CP122 | ABS | Brass | Beryllium copper | Gold plated | 30Vac-60Vdc/Max.10A |
| 13011-003 | CP201 | ABS | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.32A |
| 13011-004 | CP202 | ABS | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.32A |
| 13011-005 | CP203 | ABS | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.32A |
| 13011-006 | CP204 | ABS | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.32A |
| 13011-007 | CP205 | ABS | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.32A |
| 13011-008 | CP220 | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.32A |
|
| 13011-009 | CP221 | ABS | Brass | Beryllium copper | Nickel plated | CATII 1000V/Max.32A |
| 13011-010 | CP222 | PA | Brass | Beryllium copper | Nickel plated | CATII 1000V/Max.32A |
| 13011-011 | CP410 | PVC | Brass | Nickel plated | 30Vac-60Vdc/Max.19A |
|
| 13011-012 | CP420 | PVC | Brass | Nickel plated | 30Vac-60Vdc/Max.24A |
|
| 13011-013 | CP460 | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.32A |
|
| 13011-014 | CP450 | PA | Brass | Nickel plated | 30Vac-60Vdc/Max.36A |
|
| 13011-015 | CP451 | PA | Brass | Nickel plated | 30Vac-60Vdc/Max.36A |
|
| 13011-016 | CP452 | PA | Brass | Beryllium copper | 30Vac-60Vdc/Max.36A |
|
| 13011-017 | CP453 | PA | Brass | Beryllium copper | 30Vac-60Vdc/Max.10A |
|
| 13011-018 | CP454 | PA | Brass | Nickel plated | 30Vac-60Vdc/Max.10A |
|
| 13011-019 | CP455 | PA | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.10A |
| 13011-020 | CP456 | PA | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.10A |
| 13011-021 | CP457 | PA | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.10A |
| 13011-022 | CP458 | PA | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.36A |
| 13011-023 | CP459 | PA | Brass | Beryllium copper | Nickel plated | 30Vac-60Vdc/Max.36A |
| 13011-024 | CP470 | PA | Brass | Nickel plated | 30Vac-60Vdc/Max.10A |
|
| 13011-025 | CP480 | Brass | 30Vac-60Vdc/Max.32A |
|||
| 13011-026 | CP481 | Brass | 30Vac-60Vdc/Max.32A |
