Binding Post
- Model Code: 13009
- Brand:
Detail Specifications
| Model Code | Manufacturer Code | Insulator | Body | Surface | Rated voltage/current |
| 13009-001 | PS823 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.19A |
| 13009-002 | PS824 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.24A |
| 13009-003 | PS825 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.24A |
| 13009-004 | PS826 | ABS | Nicket plated | 30Vac-60Vdc/Max.19A | |
| 13009-005 | PS827 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.24A |
| 13009-006 | PS828 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.24A |
| 13009-007 | PS932 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.50A |
| 13009-008 | PS933 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.60A |
| 13009-009 | PS934 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.60A |
| 13009-010 | PS935 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.80A |
| 13009-011 | PS936 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.100A |
| 13009-012 | PS937 | ABS | Brass | Nicket plated | 30Vac-60Vdc/Max.100A |
